Sliding Glass Door
Our thinnest Sliding glass door profile measuring (20mm) nearly ¾”
Technical Data
Glass Options – Up to 1 ¼” glass. Impact Resistant or Insulated
LoE, Ultra Clear Low Iron Glass and tints available
Individual Panel Load – up to 882 lbs
Possibility to embed head, jamb and sill frames within the wall
Rollers can be removed and replaced without disassembly
Excellent for existing conditions and remodeling
Thermally Broken for excellent thermal and acoustic performance
Industry leading color options. Anodized, Powder Coat, Wood Grain all available or combine two tone finishes are available.
Application
Options
Sill Options
Standard
Advanced
Invisible Sill
Water Drainage Options
- Standard Weep Holes
- Concealed Drainage
Operation
- Up to 3 tracks
- Corner
- Pocket available
Additional Option
- Modern Handle
- Motorized
Sliding Glass Door Advanced & Invisible
Technical Data
Glass Options From 1 ¼” – 2 1/8” glass. Double Impact, Insulated, or Triple Glazed for northern climates.
Door stile 1” thick
Individual Panel Load – up to 1550 lbs
Up to 95 % of the opening in glass with concealed frames.
Possibility to embed head, jamb and sill frames within the wall
Rollers can be removed and replaced without disassembly
Thermally Broken for excellent thermal and acoustic performance
Concealed Drainage System
Operation: Up to 4 tracks, Corner and Pocket available
Industry leading color options. Anodized, Powder Coat, Wood Grain all available or combine two tone finishes are available
Finishes
Over 120 Finishes available with an infinite amount of possibilities
Anodized: 25 Micron – Up to 10 year warranty
Powder Coating: Up to 20 year finish warranty. Matte, Glossy, Textured, Satin, and Metallic Finishes available
Custom color: No minimum order required for custom coloring
Two Tone: Slimline Products are thermally broken as such any product can have a combination of finishes for Example: Anodized Platinum Exterior with Custom Color Powder Coated Interior
Wood Grain
